27KV Cutout Fuse
2. Current range 100A, 200A, 300A (Copper blade)
3. Fuse base material: Porcelain or Polymer
27kv Dropout Fuse Cutout
Product Picture
Features
1. Voltage range 10kV to 38kV.
2. Current range 100A, 200A, 300A (Copper blade)
3. Fuse base material: Porcelain or Polymer
4. Fuse tube made of fiber glass (filiform) with Waterproof and anti-ultraviolet coating
5. Cating part made of Electrolytic copper and zinc
6. Available normal type and loadbreak type
7. Seacoast, plateau and anti-wind design are available by request.
8. OEM is welcome
All cutouts provide reliable overcurrent protection for primary distribution systems. Overcurrent protection safeguards an electric system from excessive currents produced by abnormal conditions such as line faults, line or equipment overloads or equipment failure. For the ultimate in reliability and dependability, Product provide superior performance in harsh climates, including reduced cracking and breakage.
Model | Ratings | 1min. P.F. | Frequency | Creepage | |||||
kV | A r.m.s | ||||||||
Max. | BIL | Cont. Current | Interrupt Capacity | ||||||
Asym. | Sym. | Dry | Wet | ||||||
CEC12 (F) | 24/27 | 150 | 100 | 10000 | 7100 | 70 | 80 | 50/60 | 540 |
CEC12 (F) | 24/27 | 150 | 100 | 10000 | 7100 | 70 | 80 | 50/60 | 540 |
Hot Tags: 27kv cutout fuse, China, 27kv cutout fuse manufacturers, suppliers, factory, fuse for computer equipment, fuse for vehicle entertainment systems, control circuit fuse, fuse for capacitors, fuse for mining equipment, temperature resistant fuse
