Fuse Switch 630A

Basic Info.

Model NO.: APR630

Standard: IEC, BS

Rated Voltage: 500V

Max Current: 630A

Interruption Capacity: 100ka

Transport Package: Carton

Trademark: Cowinelec, OEM, ODM

Origin: Zhejiang, China

HS Code: 85363000

Production Capacity: 20000/Month

Product Description

* Overhead Line protecting LV

* Each Phase and the neutral with an indicator which show if the fuse or the blade are installed.

* The closure of the cap allows the switch to be closed with or w/o the fuse preventing the risk of leaving live parts exposed.

Tech. Data

Vol: 500V

Insulation Level: 1000V

Rate Amp. Fuses: 630A

Operational Current with blades: 800A

Installation Category: AC22

Short lasting Current (1s): 12kA

Dynamic Current (crest): 50kA

Interruption Capacity: 100kA

Operations behavior w/o load (oper): 800

Operations behavior (operation): 200

IP23

APR 630-Single Phase switch for NH type fuses up to 630A

General Description:

The APR630 fuse switch it is used either as an operation or protection device for LV lines. It is designed to be used with NH 1-2or 3 size fuses offering a maximum of 630 Amps of line protection without blades.

In case blades are used, the maximum switching load would be 800 Amps.

It is manufactured in reinforced fiberglass polyamide and fulfills all the necessary requirements for outdoor installation and operation.

In the APR160C model the connection is made with connectors suitable for aluminum and copper.

Conductors with a section range between

The closure of the cap allows the switch to be closed with or without a fuse, preventing the risk of leaving tension parts exposed. It may also be provided with a light emission diode (LED).
Technical Characteristics.
